Technical Details
- Pressure Class: PN10
- Working Pressure: 10 Bar
- Differential Pressure: Max 3 Bar
- Media Temperature: Max 95°c
- Temperature Stability: ± 2°c *
- Connection: External Thread (G) 1” Compression fitting (CPF)
* Valid at unchanged hot/cold water pressure, minimum flow rate 4l/min. Minimum temperature differential between hot water inlet and mixed water outlet of 10°C
Material
- Valve housing: Dezincification resistant brass, DZR
- Surface treatment: Nickel plated
PED 07/23/EC, article 3.3
Pressure equipment in conformity with PED97/23/EC, article 3.3 (sound engineering practice). According to the directive the equipment shall not carry any CE mark.
TMV3 certificate No: BC1515/214, BC1516/1214
